Driving Recorder Infrared USB Camera Module WDR 1080P IMX335 Sensor Starlight

HD Starlight Night Vision Wide Dynamic Range 1080P IMX335 with IR USB Camera Module for Dash Cam

1080P IMX335 IR Camera Module

This is an IR USB camera module with WDR (Wide Dynamic Range) and 1080P resolution, equipped with a Sony IMX335 sensor, designed for use as a dash cam. Thanks to its starlight night vision feature, this camera module provides excellent image quality in both day and night conditions.

The use of this module's WDR technology allows the camera to capture sharp images even in high-contrast lighting conditions such as bright sunlight and dark shadows. This is achieved by combining multiple images taken at different exposure levels to create a final image that always has a balanced exposure.

The Sony IMX335 sensor used in this camera module is a high-performance image sensor that provides excellent image quality even in low-light conditions. Its starlight night vision feature enables it to capture clear images in conditions that other cameras may struggle to capture, making it ideal for dash cam use.

The camera module is designed for ease of use, with a USB port for easy connection to a computer or other device. This makes it a versatile tool for a variety of applications, such as security monitoring, video conferencing, and more.

Specification

Sensor	1/2.8" IMX335
Pixel	5 Mega Pixel
Most effective pixels	1920(H)X1080(V)
Pixel Size	2.0μm x2.0μm
Compression format	MJPG / YUY2
Resolution	see above
Frame rate	see above
Shutter Type	Electronic rolling shutter
Focus type	Fixed focus
S/N ratio	TdB
Dynamic range	TdB
Interface type	USB2.0
Adjustable parameter	Brightness/Contrast/Color saturation/Hue/Definition/ Gamma/White balance/Exposure
Lens	Focal length: 3.6mm
	FOV:D180° H180°V180°F/N(2.0)
	Thread Size: M12*P0.5
Audio frequency	Support
microphone	Built-in
Power supply	USB BUS POWER
Power consumption	DC 5V, 200mA
Main chip	DSP/SENSOR/FLASH
Auto Exposure Control (AEC)	Support
Auto White Balance (AEB)	Support
Auto Gain Control (AGC)	Not Supported
Storage temperature	-20～80℃
Operating temperature	0～60℃
USB cable length	Default
Support OS	WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

Current available USB solution

0.3MP

Low cost:BF3703 BF2103 GC0329 GC0309 GC0307 GC032A OV7675

Big size:GC0308(1/6.5”) GC0328(1/6.5”) GC0403(1/3”-0.4MP) BF3A03(1/6.5”)

Global shutter:OV7251 (1/7.5”,B/W)

High frame rate:200FPS SC031GS(1/6”,B/W)

Big size with high frame rate: OV7725(1/4”,60FPS),OV7740(1/5”,60FPS)

1MP

Low cost:GC1024 GC1034 GC1064(H264) H42 H62 SP1405 OV9712 OV9732 NT99141 SC1245 OV9760

Small size for endoscope:OV9734 GC1009 HM1091

Global shutter:OV9281(1/4”,B/W) OV9782(1/4”,color) AR0144(1/4”,color) AR0135(1/3”,color)

Big size (30FPS):AR0130(1/3”,B/W) OV10635(1/2.7”,color,WDR,960P) H65(1/3”,color,960P)

2MP

Normal(10FPS):GC2145(1/5”) BF2206(1/5”)GC2335 OV2643 HM2056 BF3925 OV2755(1/5” HD)

1080P low cost:F23 F37 F35 SP2305 GC2053 GC2023 AR0330(300W) SC2232H C2390 IMX322 C2395 SC2315 AR0237

1080P small size (30FPS):OV2732(1/4”) OV2740(1/4”) OV2722(1/6”) SC2145(1/4”) HM2160(1/6”)

1080P@60FPS:OV2710 HM2131 IMX307 C2395 SC2315 F35 SC2310

1080P-HDR (30FPS): OV2735 OV2718 PS5268 IMX307

1080P-WDR (30FPS): AR0230 AR0331(300W)

1080P-Starvis (30FPS): IMX291 IMX307 IMX323 IM290

1080P big size: IMX385

1080P global shutter: OG02B10(color) OG02B1B(B/W)

5MP

500W (15FPS): OV5648 GC5025 OV5640 OV5643 OV5693(up to 30FPS) 4EC OV5650

FHD 500W(30FPS): OS05A10 PS5520 HM5532 MI5100 MT9P001 IMX335 SC5335 AR0521 JXK05 OV4689(2K,1/3”)

8MP

800W (15FPS): IMX219(1/4”)S5K3H7 IMX179 C8390

8M-4K UHD (30FPS): IMX317 IMX415 OS08A10(big size 1/1.8”)

13MP-16MP

IMX214(13M) IMX258(13M) IMMX298(16M)

USB3.0

IMX335 OV5648 IMX179 IMX307 PS5268

H264

GC1064 OV2710 OV2735 OV9732 AR0130 AR0230 AR0330 H65 H62 IMX291 IMX322 IMX323 OV2718 OV2732
