    Driving Recorder Infrared USB Camera Module WDR 1080P IMX335 Sensor Starlight

    Ask Lasest Price
    Brand Name : Sinoseen
    Model Number : SNS-GM967M-V1.0
    Certification : RoHS
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 500000 pieces/month
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    Driving Recorder Infrared USB Camera Module WDR 1080P IMX335 Sensor Starlight

    HD Starlight Night Vision Wide Dynamic Range 1080P IMX335 with IR USB Camera Module for Dash Cam

    1080P IMX335 IR Camera Module

    This is an IR USB camera module with WDR (Wide Dynamic Range) and 1080P resolution, equipped with a Sony IMX335 sensor, designed for use as a dash cam. Thanks to its starlight night vision feature, this camera module provides excellent image quality in both day and night conditions.

    The use of this module's WDR technology allows the camera to capture sharp images even in high-contrast lighting conditions such as bright sunlight and dark shadows. This is achieved by combining multiple images taken at different exposure levels to create a final image that always has a balanced exposure.

    The Sony IMX335 sensor used in this camera module is a high-performance image sensor that provides excellent image quality even in low-light conditions. Its starlight night vision feature enables it to capture clear images in conditions that other cameras may struggle to capture, making it ideal for dash cam use.

    The camera module is designed for ease of use, with a USB port for easy connection to a computer or other device. This makes it a versatile tool for a variety of applications, such as security monitoring, video conferencing, and more.


    Specification

    Sensor

    1/2.8" IMX335

    Pixel

    5 Mega Pixel

    Most effective pixels

    1920(H)X1080(V)

    Pixel Size

    2.0μm x2.0μm

    Compression format

    MJPG / YUY2

    Resolution

    see above

    Frame rate

    see above

    Shutter Type

    Electronic rolling shutter

    Focus type

    Fixed focus

    S/N ratio

    TdB

    Dynamic range

    TdB

    Interface type

    USB2.0

    Adjustable parameter

    Brightness/Contrast/Color saturation/Hue/Definition/
    Gamma/White balance/Exposure

    Lens

    Focal length: 3.6mm


    FOV:D180° H180°V180°F/N(2.0)


    Thread Size: M12*P0.5

    Audio frequency

    Support

    microphone

    Built-in

    Power supply

    USB BUS POWER

    Power consumption

    DC 5V, 200mA

    Main chip

    DSP/SENSOR/FLASH

    Auto Exposure Control (AEC)

    Support

    Auto White Balance (AEB)

    Support

    Auto Gain Control (AGC)

    Not Supported

    Storage temperature

    -20~80℃

    Operating temperature

    0~60℃

    USB cable length

    Default


    Support OS

    WinXP/Vista/Win7/Win8/Win10
    Linux with UVC(above linux-2.6.26)
    MAC-OS X 10.4.8 or later
    Android 4.0 or above with UVC


    Shenzhen Sinoseen Technology Co.,Ltd

    China top 10 camera module manufacturer

    We customize all kinds of USB/MIPI/DVP camera module as per your request


    Current available USB solution


    0.3MP

    Low cost:BF3703 BF2103 GC0329 GC0309 GC0307 GC032A OV7675

    Big size:GC0308(1/6.5”) GC0328(1/6.5”) GC0403(1/3”-0.4MP) BF3A03(1/6.5”)

    Global shutter:OV7251 (1/7.5”,B/W)

    High frame rate:200FPS SC031GS(1/6”,B/W)

    Big size with high frame rate: OV7725(1/4”,60FPS),OV7740(1/5”,60FPS)


    1MP

    Low cost:GC1024 GC1034 GC1064(H264) H42 H62 SP1405 OV9712 OV9732 NT99141 SC1245 OV9760

    Small size for endoscope:OV9734 GC1009 HM1091

    Global shutter:OV9281(1/4”,B/W) OV9782(1/4”,color) AR0144(1/4”,color) AR0135(1/3”,color)

    Big size (30FPS):AR0130(1/3”,B/W) OV10635(1/2.7”,color,WDR,960P) H65(1/3”,color,960P)


    2MP

    Normal(10FPS):GC2145(1/5”) BF2206(1/5”)GC2335 OV2643 HM2056 BF3925 OV2755(1/5” HD)

    1080P low cost:F23 F37 F35 SP2305 GC2053 GC2023 AR0330(300W) SC2232H C2390 IMX322 C2395 SC2315 AR0237

    1080P small size (30FPS):OV2732(1/4”) OV2740(1/4”) OV2722(1/6”) SC2145(1/4”) HM2160(1/6”)

    1080P@60FPS:OV2710 HM2131 IMX307 C2395 SC2315 F35 SC2310

    1080P-HDR (30FPS): OV2735 OV2718 PS5268 IMX307

    1080P-WDR (30FPS): AR0230 AR0331(300W)

    1080P-Starvis (30FPS): IMX291 IMX307 IMX323 IM290

    1080P big size: IMX385

    1080P global shutter: OG02B10(color) OG02B1B(B/W)


    5MP

    500W (15FPS): OV5648 GC5025 OV5640 OV5643 OV5693(up to 30FPS) 4EC OV5650

    FHD 500W(30FPS): OS05A10 PS5520 HM5532 MI5100 MT9P001 IMX335 SC5335 AR0521 JXK05 OV4689(2K,1/3”)


    8MP

    800W (15FPS): IMX219(1/4”)S5K3H7 IMX179 C8390

    8M-4K UHD (30FPS): IMX317 IMX415 OS08A10(big size 1/1.8”)


    13MP-16MP

    IMX214(13M) IMX258(13M) IMMX298(16M)


    USB3.0

    IMX335 OV5648 IMX179 IMX307 PS5268


    H264

    GC1064 OV2710 OV2735 OV9732 AR0130 AR0230 AR0330 H65 H62 IMX291 IMX322 IMX323 OV2718 OV2732
