    Large Size Machine Vision Industrial Robot MIPI Camera Module IMX678 4K HD

    Ask Lasest Price
    Brand Name : Sinoseen
    Model Number : SNS-678-V1.0
    Certification : RoHS
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 500000 pieces/month
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    Large Size Machine Vision Industrial Robot MIPI Camera Module IMX678 4K HD

    IMX678 4K HD global shutter large size machine vision industrial robot MIPI interface camera module


    4K HD MIPI camera module

    This is a machine vision camera module designed for industrial robot applications. It features 4K HD resolution and a large sensor for high-quality images with excellent detail.
    The camera module adopts MIPI interface, which can realize high-speed data transmission and is easy to integrate with various systems. It also features a global shutter sensor that eliminates motion artifacts and enables high-speed, distortion-free imaging.
    The camera modules are designed for operation in challenging industrial environments with a rugged housing and wide operating temperature range. It also features advanced image processing features such as auto exposure, white balance, and noise reduction to ensure high-quality images under varying lighting conditions.
    This camera module is a powerful tool for industrial robotics applications that require high-resolution imaging and reliable performance in challenging environments.

    Specification
    Pixel Size2μm x 2μm
    Effective Pixels3856 x 2180
    Image Sensor1/1.8
    Sensor Typeimx678
    Lens ViewFOV80°(Optional),F/N(Optional)
    TV Distortion<1% (Optional)
    Temperature(Operation)0~60℃
    Temperature(Storage)-20~70℃
    DimensionCustomizable


    Shenzhen Sinoseen Technology Co.,Ltd

    China top 10 camera module manufacturer

    We customize all kinds of USB/MIPI/DVP camera module as per your request


    Current available USB solution


    0.3MP

    Low cost:BF3703 BF2103 GC0329 GC0309 GC0307 GC032A OV7675

    Big size:GC0308(1/6.5”) GC0328(1/6.5”) GC0403(1/3”-0.4MP) BF3A03(1/6.5”)

    Global shutter:OV7251 (1/7.5”,B/W)

    High frame rate:200FPS SC031GS(1/6”,B/W)

    Big size with high frame rate: OV7725(1/4”,60FPS),OV7740(1/5”,60FPS)


    1MP

    Low cost:GC1024 GC1034 GC1064(H264) H42 H62 SP1405 OV9712 OV9732 NT99141 SC1245 OV9760

    Small size for endoscope:OV9734 GC1009 HM1091

    Global shutter:OV9281(1/4”,B/W) OV9782(1/4”,color) AR0144(1/4”,color) AR0135(1/3”,color)

    Big size (30FPS):AR0130(1/3”,B/W) OV10635(1/2.7”,color,WDR,960P) H65(1/3”,color,960P)


    2MP

    Normal(10FPS):GC2145(1/5”) BF2206(1/5”)GC2335 OV2643 HM2056 BF3925 OV2755(1/5” HD)

    1080P low cost:F23 F37 F35 SP2305 GC2053 GC2023 AR0330(300W) SC2232H C2390 IMX322 C2395 SC2315 AR0237

    1080P small size (30FPS):OV2732(1/4”) OV2740(1/4”) OV2722(1/6”) SC2145(1/4”) HM2160(1/6”)

    1080P@60FPS:OV2710 HM2131 IMX307 C2395 SC2315 F35 SC2310

    1080P-HDR (30FPS): OV2735 OV2718 PS5268 IMX307

    1080P-WDR (30FPS): AR0230 AR0331(300W)

    1080P-Starvis (30FPS): IMX291 IMX307 IMX323 IM290

    1080P big size: IMX385

    1080P global shutter: OG02B10(color) OG02B1B(B/W)


    5MP

    500W (15FPS): OV5648 GC5025 OV5640 OV5643 OV5693(up to 30FPS) 4EC OV5650

    FHD 500W(30FPS): OS05A10 PS5520 HM5532 MI5100 MT9P001 IMX335 SC5335 AR0521 JXK05 OV4689(2K,1/3”)


    8MP

    800W (15FPS): IMX219(1/4”)S5K3H7 IMX179 C8390

    8M-4K UHD (30FPS): IMX317 IMX415 OS08A10(big size 1/1.8”)


    13MP-16MP

    IMX214(13M) IMX258(13M) IMMX298(16M)


    USB3.0

    IMX335 OV5648 IMX179 IMX307 PS5268


    H264

    GC1064 OV2710 OV2735 OV9732 AR0130 AR0230 AR0330 H65 H62 IMX291 IMX322 IMX323 OV2718 OV2732
