8mp Usb Camera Module Sony imx317 4k FHD For Security Surveillance

Ask Lasest Price
Brand Name :	Sinoseen
Model Number :	SNS-DZ1009-V1.0
Certification :	RoHS
Price :	negotiable
Payment Terms :	T/T
Supply Ability :	500000 pieces/month
Delivery Time :	2-3weeks

Add to Cart

Product Details
Company Profile

8mp Usb Camera Module Sony imx317 4k FHD For Security Surveillance

OEM 8MP SONY IMX317 4K FHD USB Camera Module for Security Surveillance Face Recognition

8MP 4K 30FPS USB2.0 Camera Module

This is our hot selling 4K FHD USB camera module, it adopts SONY IMX317 CMOS sensor, the image quality is very stable. The biggest advantage of this camera module is that it supports a high frame rate of 30FPS at full resolution (3840x2160), while most other 8MP sensors can only support a frame rate of 15FPS at 8MP. The module can receive a larger amount of incoming light, has good photosensitive performance, clearer pictures, and clearer still pictures. Recovery is better.

This module can be used in high-definition photography, video surveillance, video conferencing all-in-one machine, video teaching, Internet of Things, aerial photography UAV, QR code recognition and other fields

This camera module is standard 38MMx38MM (compatible with 32MMx32MM), you can use this design to customize your own camera module, after your test, we can change the size and shape of the module according to your requirements. Additionally, we offer a wide range of different FOV lenses from 20° to 200°.

Specification:FHD Camera Module

Model No	SNS-DZ1009-V1.0
Sensor	1/2.5’’ SONY IMX317 CMOS
Pixel	8 Mega Pixel
Most effective pixels	3840(H) x 2160(V)
Pixel Size	1.62µm x 1.62µm
Image area	3864um (H) x 2196um (V)
Compression format	MJPEG / YUV2 (YUYV)
Resolution & Frame rate	See above
Shutter Type	Electronic rolling shutter
Focus type	Fixed focus
Chroma	Color, RGB
Clock Frequency	6 to 72 MHz
Microphones	Built-in
Interface type	USB2.0
Adjustable parameter	Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure
Lens	Lens construction: 5E+IR
	H FOV: 90 degree
	Thread Size: M12*P0.5
Audio frequency	Optional
Power supply	USB BUS POWER
Operating Voltage	DC 5V
Operating Current	260mA
Main chip	DSP/SENSOR/FLASH
Auto Exposure Control (AEC)	Support
Auto White Balance (AEB)	Support
Auto Gain Control (AGC)	Support
Dimension	38MMx38MM (32MMx32MM)
Storage temperature	-20°C to 70°C
Operating temperature	0°C to 60°C
USB cable length	Default
Support OS	WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

Camera Module Application Areas

Imaging and vision solutions Integrated complex and customized technology
Machine vision Intelligent Systems
Future Security Optical technology solutions
Camera Module Customized solutions Internet of Things End-to-End Solution
Iris recognition technology Iris Solutions
Face recognition VR High End Camera Solutions
Smart home solutions Intelligent hardware solutions
Professional camera Modules Specially designed for small UAV
Airborne camera Modules UAV solutions
UAV Special Modules Drone solutions
Aerial filming solutions Optical Technology solutions
Mobile Phone Camera module Camera solutions
Optronics Solutions Imaging Technology Solutions
Video technology solutions Optoelectonic research
Infrared Imagers for Industry Embedded Systems solutions
