Drive Free 8 Mega Pixel USB Camera Module 4K Samsung S5K3H7 Sensor

Ask Lasest Price
Brand Name :	Sinoseen
Model Number :	SNS-8MP-3H7-V1.0
Certification :	RoHS
Price :	negotiable
Payment Terms :	T/T
Supply Ability :	500000 pieces/month
Delivery Time :	2-3weeks

Add to Cart

Product Details
Company Profile

Drive Free 8 Mega Pixel USB Camera Module 4K Samsung S5K3H7 Sensor

Drive Free 8 Mega Pixel Uhd Camera Module 4K Samsung S5K3H7 Sensor

8MP USB2.0 Camera Module with Samsung 3H7 Cmos sensor UVC Compliant drive free

USB Camera Module 4K

This is one of our 4K camera module, it is 8MP (3840x2160) resolution with Samsung 3H7 CMOS sensor, image quality is quite excellent and stable. The biggest advantage of this camera module is that it supports 30FPS high frame rate at full resolution 8MP (3840x2160), while most of other 8MP sensor can only support 15FPS frame rate at 8MP

Specification

Model No	SNS-8MP-3H7-V1.0
Sensor	1/2.5’’ Samsung 3H7 CMOS
Pixel	8 Mega Pixel
Most effective pixels	3264(H) x 2448(V)
Pixel Size	1.4µm x 1.4µm
Image area	3864um (H) x 2196um (V)
Compression format	MJPEG / YUV2 (YUYV)
Resolution & Frame rate	See above
Shutter Type	Electronic rolling shutter
Focus type	Fixed focus
Chroma	Color, RGB
Clock Frequency	6 to 72 MHz
Microphones	Built-in
Interface type	USB2.0
Adjustable parameter	Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure
Lens	Focal length: 3.6mm
	Lens construction: 5E+IR
	H FOV: 90 degree
	Thread Size: M12*P0.5
Audio frequency	Optional
Power supply	USB BUS POWER
Operating Voltage	DC 5V
Operating Current	260mA
Main chip	DSP/SENSOR/FLASH
Auto Exposure Control (AEC)	Support
Auto White Balance (AEB)	Support
Auto Gain Control (AGC)	Support
Dimension	Customizable
Storage temperature	-20°C to 70°C
Operating temperature	0°C to 60°C
USB cable length	Default
Support OS	WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC

Drive Free 8 Mega Pixel USB Camera Module 4K Samsung S5K3H7 Sensor

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

FAQ:

Q1. How to choose the right camera module?
A: Please tell us your specific needs, such as application scenarios, resolution, size, and lens requirements. We will have a professional team of engineers to assist you in choosing the most suitable camera module.

Q2. How to start proofing?
A: After confirming all the parameters, we will draw a drawing to confirm the details with you. Once the drawing is confirmed, we will arrange a proofing.

Q3: How do I send the payment?
A: Currently we accept T/T bank transfer and Paypal.

Q4: How long does it take to make a sample?
A: If it is a USB camera module, it usually takes 2-3weeks, if it is a MIPI or DVP camera module, it usually takes 10-15days.

Q5: How long will it take to receive the sample after it is ready?
A: After the samples have been tested and there is no problem, we will send the samples to you via DHL FedEx UPS or any other courier methods, usually within a week.
