    OV5648 5MP AF Plug And Play Raspberry Pi Camera Module USB For Face Recognition

    Ask Lasest Price
    Brand Name : Sinoseen
    Model Number : SNS-DZ1018-V1.0
    Certification : RoHS
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 500000 pieces/month
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    OV5648 5MP AF Plug And Play Raspberry Pi Camera Module USB For Face Recognition

    5 million OV5648 AF plug and play support Raspberry Pi USB2.0 camera module for face recognition


    Auto Focus USB camera module

    This is a USB camera module based on OV5648, 5 million high-definition pixels, auto-focus function, the interface type is USB2.0, and the picture resolution is up to 2592×1944.
    Support UVC protocol, no need to drive, plug and play. And the mod is small enough to be easily embedded into various devices. Raspberry Pi and Jetson Nano are supported.
    It can be used for high-definition cameras, high-definition recognition, education booths, face recognition, security monitoring, video conferencing all-in-one machines, advertising machines, etc.


    Specification

    Model No

    SNS-DZ1018-V1.0

    Sensor

    1/4’’ Omnivision OV5648

    Pixel

    5 Mega Pixel

    Most effective pixels

    2592(H) x 1944(V)

    Pixel Size

    1.4µm x 1.4µm

    Image area

    3673.6µm x 2738.4µm

    Compression format

    MJPG/YUY2

    Resolution & Frame rate

    See above

    Shutter Type

    Electronic rolling shutter

    Focus type

    Auto Focus

    S/N ratio

    34dB

    Dynamic range

    67dB @ 8x gain

    Sensitivity

    690mV / lux-sec

    Interface type

    USB2.0 high seepd

    Adjustable parameter

    Brightness/Contrast/Color saturation/Hue/Definition/
    Gamma/White balance/Exposure

    Audio frequency

    Optional

    Power supply

    USB BUS POWER

    Power consumption

    DC 5V, 200mW

    Main chip

    DSP/SENSOR/FLASH

    Auto Exposure Control (AEC)

    Support

    Auto White Balance (AEB)

    Support

    Auto Gain Control (AGC)

    Support

    Operating temperature

    30°C to 70°C

    USB cable length

    Default

    Support OS

    WinXP/Vista/Win7/Win8/Win10
    Linux with UVC(above linux-2.6.26)
    MAC-OS X 10.4.8 or later
    Android 4.0 or above with UVC
