USB OV7251 Global Exposure 120FPS USB Camera Module for Machine Vision Inspection​

global shutter usb Camera Module

This is a low power consumption OV7251 camera module. It uses a global shutter to reduce or eliminate unwanted image artifacts that occur with conventional rolling shutter image sensors due to motion during image capture. The module's global shutter and excellent low-light sensitivity make it useful for any application requiring gesture detection, head and eye tracking, and depth and motion detection.

The black and white sensor used in this module utilizes the industry's smallest global shutter pixel and is capable of capturing VGA (640×480) resolution video at 120 frames per second and QVGA at 180 fps with merge and skip (320×240), QQVGA (160×120) captured at 360 fps. Its high frame rate makes it an ideal solution for low-latency machine vision applications.

The compact form factor of this module makes it an attractive camera solution for applications such as iris recognition, machine vision inspection, robot vacuums, and more. Also, the low power consumption of this module makes it an ideal dedicated module for similar applications.

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

Current available global shutter USB camera module

Omnivision OV7251 0.3MP Monochrome(black and white)

Omnivision OV9281 1MP Monochrome(black and white)

ON Semiconductor AR0144 1MP Monochrome(black and white) or RGB color

Omnivision OG02B1B 2MP Monochrome(black and white)

Omnivision OG02B10 2MP RGB color
