    720P 1280*720 Fixed focus USB2.0 30FPS with IMX056 CMOS sensor camera module for High-end smartphones

    Ask Lasest Price
    Brand Name : Sinoseen
    Model Number : SNS-DZ1134-V1.0
    Certification : RoHS
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 500000 pieces/month
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    720P 1280*720 Fixed focus USB2.0 30FPS with IMX056 CMOS sensor camera module for High-end smartphones

    720P 1280*720 Fixed focus USB2.0 30FPS with IMX056 CMOS sensor camera module for High-end smartphones

    The module offers a resolution of 1280720 pixels, commonly known as 720P, which provides clear and detailed images and videos. It has a fixed-focus lens, which means that the focus is set at a specific distance and cannot be adjusted manually. This allows for easy and worry-free operation, ensuring clear images without manual adjustments. The camera module supports USB2.0 interface, making it compatible with a wide range of devices, including smartphones, tablets, and computers. The USB2.0 interface enables fast data transfer and ensures smooth video streaming. It offers a frame rate of 30 frames per second (FPS). This high frame rate enables smooth video recording, ensuring that fast-moving objects are captured without motion blur. The camera module is equipped with the IMX056 CMOS sensor, which is known for its excellent image quality and low-light performance. The CMOS sensor captures clear and vivid images even in challenging lighting conditions.

    Overall, the 720P 1280*720 Fixed Focus USB2.0 30FPS Camera Module with IMX056 CMOS Sensor is a high-end component that enhances the imaging capabilities of smartphones, allowing users to easily capture high-quality photos and videos.


    Specification

    Module

    SNS-DZ1134-V1.0

    SensorIMX056 CMOS
    Image sensor size1/5 inch
    Pixel1MP
    Most effective pixels1280*720
    Pixel Size3.0um*3.0um
    Frame rate30fps
    Focus typeFixed focus
    Output interfaceUSB2.0
    Video outputMJPG/YUV
    Output formatsRAW Bayer 10bits
    Max S/N ratioTBD
    DynamicTBD
    Storage temperature-20°C to 70°C
    Operating temperature0°C to 60°C
    Support OSWinXP/Vista/Win7/Win8/Win10
    Linux with UVC(above linux-2.6.26)
    MAC-OS X 10.4.8 or later
    Android 4.0 or above with UVC

    720P 1280*720 Fixed focus USB2.0 30FPS with IMX056 CMOS sensor camera module for High-end smartphones720P 1280*720 Fixed focus USB2.0 30FPS with IMX056 CMOS sensor camera module for High-end smartphones
