    2MP 1600*1300 MIPI with OV2312 60fps RGB-IR Global Shutter CMOS sensor for Automobile industry camera module

    Ask Lasest Price
    Brand Name : Sinoseen
    Model Number : CK-21854-V1.0
    Certification : RoHS
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 500000 pieces/month
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    2MP 1600*1300 MIPI with OV2312 60fps RGB-IR Global Shutter CMOS sensor for Automobile industry camera module

    2MP 1600*1300 MIPI with OV2312 60fps RGB-IR Global Shutter CMOS sensor for Automobile industry camera module


    2MP 1600*1300 MIPI camera module


    The OV2312 is a 1/5-inch CMOS image sensor produced by OmniVision Technologies. It is a popular choice for compact camera modules due to its small size and good performance.

    This camera module has a resolution of 1600 x 1300 pixels, which is a 2MP image resolution. The key highlight of this module is its high frame rate of 60 FPS, which can be particularly useful for applications that require capturing fast-moving subjects or need high-speed video capture.

    The MIPI interface allows for easy integration of this camera module with compatible host processors, making it suitable for a variety of mobile devices, embedded systems, and other applications where a compact, high-performance camera solution is required.

    The compact design of this module is an important feature, as it enables seamless integration into space-constrained devices and systems, making it a versatile choice for various applications.

    Overall, this 2MP camera module with the OV2312 sensor, 1600 x 1300 resolution, 60 FPS frame rate, and MIPI interface can be a good option for projects or applications that require a compact, high-speed imaging solution, such as in the areas of robotics, security, machine vision, and mobile device imaging.


    Specification

    ModuleCK-21854-V1.0
    SensorOV2312 CMOS
    Pixel2MP
    Most effective pixels1600*1300
    Pixel Size3um*3um
    Image area4857.7um*3955.9um
    Frame rate30fps
    Shutter TypeGlobar shutter
    Focus typeFixed focus
    S/N ratio37.4 dB
    Dynamic range68 dB
    Power supply

    analog:2.8v

    core:1.2v

    I/O:1.8v

    Output interface2-lane MIPI serial output and DVP parallel output
    Output formats10-bit RGB-IR RAW
    lens size1/2.9'
    Storage temperature-20°C to 70°C
    Operating temperature0°C to 60°C
    Support OSWinXP/Vista/Win7/Win8/Win10
    Linux with UVC(above linux-2.6.26)
    MAC-OS X 10.4.8 or later
    Android 4.0 or above with UVC

    2MP 1600*1300 MIPI with OV2312 60fps RGB-IR Global Shutter CMOS sensor for Automobile industry camera module2MP 1600*1300 MIPI with OV2312 60fps RGB-IR Global Shutter CMOS sensor for Automobile industry camera module2MP 1600*1300 MIPI with OV2312 60fps RGB-IR Global Shutter CMOS sensor for Automobile industry camera module
