Brand Name : | Sinoseen |
Model Number : | SNS-DZ1147-V1.0 |
Certification : | RoHS |
Price : | negotiable |
Payment Terms : | T/T |
Supply Ability : | 500000 pieces/month |
Delivery Time : | 2-3weeks |
2MP 1920*1080 Fixed focus USB interface 25FPS with PS5268 sensor camera module for Driving Recorder
The PS5268 is a 2-megapixel (2MP) CMOS image sensor capable of
capturing 1920 x 1080 full HD (1080p) video at 25 frames per second
(FPS). It is a fixed-focus camera module with a USB interface.
Key features of the PS5268 camera module:
Resolution: The sensor has a resolution of 2MP (1920 x 1080
pixels), which allows it to capture full HD 1080p video.
Frame Rate: The camera module can record video at 25 FPS, which
provides smooth motion capture.
Fixed Focus: The camera module has a fixed-focus lens, simplifying
the design and reducing the cost compared to autofocus or varifocal
lenses.
USB Interface: The camera module communicates through a USB
interface, making it easy to integrate with a variety of devices,
such as computers, laptops, or embedded systems that support USB
connectivity.
Applications: This type of camera module is well-suited for
applications that require a basic, cost-effective full HD camera
solution, such as security and surveillance systems, webcams, IoT
devices, and various embedded imaging applications.
The PS5268 2MP 1920 x 1080 fixed-focus camera module with a USB
interface provides a balance between image quality, frame rate, and
ease of integration. It can be a suitable choice for projects or
applications that need a reliable, high-definition camera input
with a straightforward USB connectivity option.
Specification
Module | SNS-DZ1147-V1.0 |
Sensor | PS5268 CMOS |
Image sensor size | 1/2.7 inch |
Pixel | 2MP |
Most effective pixels | 1920*1080 |
Pixel Size | 3.0um*3.0um |
Frame rate | 25fps |
Optical distortion | <-0.5% |
Image sensor Data output | RAW Data 10bits |
Focus type | Fixed focus |
Output interface | USB2.0 |
Video output | MJPG/YUV |
Output formats | RAW Bayer 10bits |
Max S/N ratio | TBD |
Dynamic | TBD |
Storage temperature | -20°C to 70°C |
Operating temperature | 0°C to 60°C |
Support OS | WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC |
![]() |
